| Colors | Desert Yellow, Silver, Shadow White, Polar Night Black, Furious Orange | ||
| Front suspension | Double A-frame with stabilizer bar, stroke 230mm | ||
| Front shock absorbers | Adjustable gas shock absorber | ||
| Rear suspension | Independent torsion trailing upper arm suspension, stroke 250mm | ||
| Rear shock absorbers | Adjustable gas shock absorber | ||
| Front tyres | 25 × 8 × 12 in & 26 × 9 × 14 in | ||
| Rear tires | 25 × 10 × 12 in & 26 × 11 x 14 in | ||
| Rims | 12 in. Aluminum & 14 in. Aluminium | ||
| Brakes | Dual 220 mm disc brakes | ||
| Engine type | 4-stroke SOHC V-twin cylinder | ||
| Horsepower / Displacement | 48 HP / 500 CC | ||
| Fuel System / Cooling | EFI/Liquid | ||
| Gearbox | CVT L / H / N / R / P | ||
| Traction system | Selectable 2WD/4WD with differential lock | ||
| L x W x H | 2150 × 1250 × 1400 mm | ||
| Wheelbase | 1500 mm | ||
| Ground clearance | 305 mm | ||
| Unladen mass | 399 kg | ||
| Towing | 697 kg | ||
| Fuel tank capacity | 30 L | ||
| Seat height | 95 cm | ||
| Redstone 550 R2 ET | Redstone 550 R2 MD | Redstone 550 R2 DL | |
| Power steering | - | EPS | EPS |
| Wheels | 12" alloy wheels | 14" alloy wheels | 14" beadlock alloy wheels |
| Display | LCD | TFT | TFT |
| Tyres | 25" Wanda | 26" Wanda | 26" Wanda |
| Winch | 2500 lb steel cable | 3500 lb steel cable | 3500 lb synthetic rope |
| Shock absorbers | Oil | Gas | Gas |
| Starter | Key start | Key start | Start button |
| Diff lock | - | Rear | Rear |
