| Name | Chinchilla 300 | Front/Rear Brakes | Disc |
| Version | TCS | Maximum speed (km/h) | 129km/h |
| Type | BD300-15 | ABS | Front and rear |
| Clutch | Normal clutch | ||
| Engine type | V-Twin cylinders, 8 valves, water-cooling | Max. torque (N.m/r/min) | 27N.m/6500rpm |
| Engine model | BD2V58MN | Compression ratio | 11.5 : 1 |
| Displacement | 298cc | Cylinder diameter * gear | 58*56.4mm |
| Max Power | 22kW / 8500rpm | Transmission System | Belt drive |
| Wheelbase | 1420mm | P×W×K (mm) | 2120*826*1050mm |
| Seat height | 690 mm | Curb weight | 175 kg |
| Type of | LED | Shock absorber type | Front inverted shock absorbers, rear spring shock absorber |
| Ground Clearance | 158mm | Fuel Tank Capacity (L) | 15L |
| Front tire | 120/80-16 | Rear tire | 150/80-15 |
| Frame | Cradle-type steel frame, aluminum alloy rear fork | ||
